Customize
A. Voltage:3.7V to 100V+.
B. Capacity:2AH to 200AH+
C. Size:Any size,According to your requirements
D. Shape:Triangle/long/flat/cylindrical,or any shape as per your requirements.
| Nominal Capacity : | 14Ah | Nominal voltage : | 52V | Size : | 93*135*360mm |
|---|---|---|---|---|---|
| Weight : | around 5.0kg | Max charge voltage : | 54.6V | Max charge Current : | 3A |
| Continious running current : | 10A | Brust current : | 30A | Charge temperature : | 0°C~ 50°C |
| discharge temperature : | -20°C~ 60°C | Cycle life : | >=600times |
BMS
A. 10Amp, 20Amp,30Amp,50Amp,80Amp,100Amp or higher.
B. Can add Power display,USB charging connector etc.
C. Communication/balance fuction.
D. According to your requirements.
Cells Choose
Samsung: 22F,22P,25R,,30B,30Q,35E etc.
LG: M26,MJ1,HE2,HE4,HG2.
Panasonic/Sanyo: 18650PF,18650A,18650B,18650GA.
Sony: VTC4,VTC5,VTC6.
Wire /Connector
XT60,XT90 /Anderson 30A,50A,120A, Aviation/ Canon, DC Connector,bare wire etc,or as per your requirements.
Delivery Time
Sample: 7days.
More than 500packs: 12days.
More than 10K packs: 25days.
For special condition the delivery date will be adjusted with customers.
Others
More, will be updated!
